SpaceX Starship Mass Distribution
Adjust the payload mass to see how it affects the distribution of mass in the Starship system heading to Mars.
Payload Mass: 50 tons(0-150 tons)
Absolute Mass Distribution (tons)
Mass Summary
- Total Mass: 4945 tons
- Fuel Percentage: 92.5%
- Dry Mass Percentage: 6.5%
- Payload Percentage: 1.0%
Nuclear Reactor Options for Mars Rescue Mission
| Reactor Type | Power Output (kWe) | Fuel Type | Key Safety Features | Development Status | Suitability for Rescue Mission |
|---|---|---|---|---|---|
| Radioisotope Thermoelectric Generator (RTG) | ~0.11 | Plutonium-238 | Simple, no moving parts | Operational on Mars | Insufficient power for primary mission needs |
| Kilopower Heat Pipe Reactor | 1-10 (scalable) | Enriched Uranium-235 | Inherently safe, passive heat removal, self-regulating | Prototype tested successfully (KRUSTY) | Strong candidate due to scalability and demonstrated technology |
| Fission Surface Power (FSP) | ≥ 40 | Low-Enriched Uranium | Robust, reliable for crew safety | Under development, lunar demonstration planned | Excellent candidate for high power demands |
| SAFE-400 | 100 | Uranium Nitride | No positive void reactivity coefficient | Development in early 2000s, less recent research | Potentially high power, but development status less certain |
| Uranium Molten Salt Reactor (UMSR) | Conceptual | Uranium-233 (from Th-232) | Reduced weight, efficient heat transfer | Conceptual | Not a near-term solution due to conceptual nature and fuel source |
Colony Dashboard
To manage efficiently manage, maintain and grow the different components of a Mars colony we developed a dashboard that provides an overview over the state of all systems relevant to the inhabitant's survival. Key metrics such as energy consumption and production, current irradiation values and greenhouse temperature can me instantly monitored and controlled. This allows for fast response in case of hazardous situations and malfunctions.
Nuclear Reactor Status
Current power generation and consumption metrics
Current Power370 kW
Fuel Level78%
Reactor Efficiency92%
24-Hour Power Profile
Power Consumption by System
Life Support
120 kW
Agriculture
95 kW
Research
60 kW
Comms
45 kW
Other
40 kW
Atmospheric Regulation Status
Solid oxide electrolysis/ Electrolysis of water ice
Oxygen Level21.2%
18%21%24%
CO₂ Level820 ppm
40010002000
Pressure101.3 kPa
Temperature22.6°C
s
10°C22°C30°C
Air Filtration Efficiency96%
Next maintenance scheduled: 14 days
24-Hour Atmospheric Trends
O₂ Generation
Normal
CO₂ Scrubbers
Optimal
HVAC
Normal
Landing Position and water availability
The Landing position based on the stranded Aristronaut's position will determine the water availability and temperature around the settlement. If stranded at one of Mars' poles, the Aristraunaut will be able to take advantage of abundant water ice. Accessing this water is essential for both life support and potential propellant production. Several technologies can be employed for water ice extraction.
Water Systems Status
Water ice near the Martian poles
Temperature24.5°C
10°C25°C40°C
Humidity65%
Weekly Gas Exchange
Plant Health Status
Water: 340 L/day
Lettuce
95%
Potatoes
87%
Tomatoes
92%
Soybeans
80%
Wheat
88%
Food Supply Status
Thermal treatment/ chemical leaching of soil, Controlled Environment Agriculture (CEA)
Total Food Supply
8,600 kg
Supply Alert
Daily Balance
+42 kg/-38 kg
Est. Supply Duration: -2150 days
Food Supply by Category
Nutritional Profile
Carbs52%
Protein25%
Fat23%
2250 kcal daily per colonist
System Efficiency
Food Waste3.2 kg/day
Storage Utilization72%
Processing Efficiency91%
Production
Normal
Storage
Optimal
Processing
Normal
